The semi-mounted plough for the highest requirements

Diamant 16 is built for performance and equipped with all our technologies to help you achieve a high level of productivity. On the road or in the field, you will appreciate the comfort!

Contact your dealer!

Diamant 16: easy handling & high efficiency

Quality & safety on the road

The semi-mounted reversible plough is rotated into its centre position and locked via two stop valves for quick and safe road transport.

  • Safely towed behind the tractor (like any single-axle trailer)
  • Protection against excessive loads through a damper for the transport wheel
  • The ModuLight LED provides maximum safety
Diamant 16 transport on the street

Select a model

Technical data

Diamant 16 5 L 100 Diamant 16 5+1 L 100 Diamant 16 6 L 100 Diamant 16 6+1 L 100 Diamant 16 7 L 100 Diamant 16 7+1 L 100 Diamant 16 8 L 100 Diamant 16 8+1 L 100 Diamant 16 5 L 120 Diamant 16 5+1 L 120 Diamant 16 6 L 120 Diamant 16 6+1 L 120 Diamant 16 7 L 120 Diamant 16 7+1 L 120
Power requirements (hp) minimum of 150 150 150 150 150 150 180 180 150 150 150 150 150 180
Power requirements (kW) minimum of 110 110 110 110 110 110 132 132 110 110 110 110 110 132
Weight (kg) 2 584 2 834 2 830 3 080 3 076 3 326 3 322 3 572 2 634 2 896 2 892 3 154 3 150 3 412
Working width per furrow (cm) 33, 38, 44, 50 33, 38, 44, 50 33, 38, 44, 50 33, 38, 44, 50 33, 38, 44, 50 33, 38, 44, 50 33, 38, 44, 50 33, 38, 44, 50 40, 45, 53, 60 40, 45, 53, 60 40, 45, 53, 60 40, 45, 53, 60 40, 45, 53, 60 40, 45, 53, 60
Number of furrows 5 5+1 6 6+1 7 7+1 8 8+1 5 5+1 6 6+1 7 7+1
Body spacing (cm) 100 100 100 100 100 100 100 100 120 120 120 120 120 120

Basic equipment

  • Headstock with lower link attachment Cat. 3 (or Cat. 3N=L2 Z3, Cat. 4N= L3 Z4 or Cat. 4)
  • Box section frame 160 x 160 x 10 mm
  • Toolbox, tools and shearbolts
  • Stand
  • Underframe clearance 80 cm
  • Mechanical depth adjustment
  • Wheel 400/55-22.5, 1.020 x 400 mm with suspension and schock absorber
  • Two-piece shares, hard-faced (option: hard-faced one-piece stone shares or points in angled version)
  • Shape of Dural bodies B, C, D or W

The availability and basic equipment of the machine may vary depending on the country. Please contact your dealer.
