Solitair F

  • 4 metering units for up to 4 width sections
  • Pressure-resistant single or double tank with steel lid
  • Allows sowing using the single shot or double shot method
Pneumatic seed drill LEMKEN Solitair F Front view with front tank
Pneumatic seed drill LEMKEN Solitair F View from above
 Pneumatic seed drill LEMKEN Solitair F Rear view
 Pneumatic seed drill LEMKEN Solitair F
Pneumatic seed drill LEMKEN Solitair F Side view

Precise sowing from front to back

Front-rear combinations are becoming increasingly popular for sowing. The Solitair F front tank can be combined with different sowing methods, such as single seed drilling or coulter bars at the rear, maximising the number of days in the field. Thanks to its balanced weight distribution it can be used with smaller tractors with a lower lifting capacity. This not only reduces operating costs, but also makes the machine combination very agile.

Delivery rates are decisive

The Solitair F front tank is pressure-resistant and therefore able to handle even high application rates. The 2,400 litre double tank can be used for both single shot and double shot sowing.

Highly precise metering

The Solitair F has four modular metering units. As a result, it is suitable for both single shot and double shot sowing. Seed is guided to the rear either to the right of the tractor or optionally underneath the tractor.

If the Solitair F is used as a single tank, a combination with four width sections isalso possible, for example with a precision seed drill or an OptiDisc coulter barwith 6 m working width.

Metering of LEMKEN Solitair F

Maximum utilisation

Optimum soil contact is one of the basic prerequisites for high crop yields. To achieve this, the Solitair F features a front mounting space, where a tyre packer or an external weight of up to 800 kg can be mounted. This creates an optimal weight distribution and therefore ensures safety and a comfortable ride.

The steerable trailed tyre packer can optionally be mounted on the tractor as a front tyre packer. It can also be ballasted with suitcase weights of up to 500 kg.

Optimum soil contact LEMKEN Solitair F

Technical data

Solitair F/2400 Einzelbehälter Solitair F/2400 Doppelbehälter
Weight (kg) 1900 1900
Tank capacity (litres) 2400 2400
Transport width (m) 2,45 2,45
Length 170 170
Filling opening single tank 220 x 80 140 x 80 / 80 x 80
Filling level 160 160

Basic equipment

  • Preparation for operation with any ISOBUS Terminal (ISOBUS Terminal not included)
  • Hydraulically driven fan
  • Mounting to front hydraulics, lower link attachment Cat. 3N=L2 Z3 (or Cat. 2)
  • Transport box
  • 4 electrically driven single metering units
  • Electronic hopper level indicator
  • Version pressure system
  • Hopper cover pressure-resistant, rear folding
  • 2 metering wheel sets
  • Hose to the combination implement routed next to the tractor
  • Tool-free hose coupling
  • Width sections electrically remote-controlled
  • Frame integrated stands
  • Loading platform with steps
  • Lighting equipment Europe
  • Lighting equipment North America
  • Speed signal via TECU

The availability and basic equipment of the machine may vary depending on the country. Please contact your dealer.

Download the Solitair F flyer

All information in compact form in the flyer

File type:
PDF
Size:
211.18 KB

All information in compact form in the flyer

Download
