Solitair 25 KA

  • Nominal hopper volume: 3 000 L
  • From 4 m to 6 m working width

Versatile drilling methods

The Solitair 25 KA pneumatic seed drill has been specially developed to work in a wide variety of conditions. The implement can be combined with a range of different tillage implements and coulter bars for maximum utilisation.

Contact your distribution partner!

Advantages of Solitair 25

  • With a newly developed metering and distribution system, the Solitair 25 KA can be used as both a seed hopper and a fertiliser, which opens up a wide variety of applications.
  • Four electrically operated metering units deliver precise application rates between 0.5 and 500 kg/ha, as seeds flow continuously and evenly at all times due to a fine balance between chamber volume and speed of rotation.
  • The new blower fan has a stainless steel wheel and an aluminium housing which is integrated in the tank. This generates an adequate volume of air while keeping noise levels low.
  • The implement is optionally available with a weighing unit and filling auger to help refilling and shorten waiting times.
  • The parallelogram-guided double disc coulter system with depth control roller is available in a mechanical version (up to 45 kg coulter pressure) and a hydraulic version (up to 70 kg coulter pressure).

Select a model

Technical data

Solitair 25/400 KA Solitair 25/450 KA Solitair 25/500 KA Solitair 25/600 KA
Working width (cm) 400 450 500 600
Weight (kg) 1 967 2 098 2 215 2 478
Article number 750 5330 750 5331 750 5332 750 5333
Tank capacity (litres) 3 000 3 000 3 000 3 000
Number of rows with row spacing 12.5 cm (15cm) 32 (27) 36 (30) 40 (34) 48 (40)

Basic equipment

  • Electronic seed drill control MegaDrill with preparation for operation with any ISOBUS terminal
  • Hydraulically driven fan
  • Maintenance-free double disc coulters OptiDisc M, up to 45 kg coulter pressure per coulter
  • Forward folding hopper cover
  • Hopper with distributors located outside
  • Electronic hopper level indicator via 2 sensors at seed hopper (top)
  • 4 electrically driven metering units
  • Digital scale with case
  • Width sections electrically remote-controlled
  • Pulse wheel for MegaDrill, Ø 340 mm
  • Loading platform with steps
  • Without lighting equipment

The availability and basic equipment of the machine may vary depending on the country. Please contact your dealer.
