Solitair 25 KA

  • Nominal hopper volume: 3 000 L
  • From 4 m to 6 m working width
Solitair 25 im Einsatz
Solitair 25 aus der Vogelperspektive
Solitair 25 bei der abendlichen Befüllung
Solitair 25 Behälter
Solitair 25 stehend

Versatile drilling methods

The Solitair 25 KA pneumatic seed drill has been specially developed to work in a wide variety of conditions. The implement can be combined with a range of different tillage implements and coulter bars for maximum utilisation.

Contact your distribution partner!

Advantages of Solitair 25

  • With a newly developed metering and distribution system, the Solitair 25 KA can be used as both a seed hopper and a fertiliser, which opens up a wide variety of applications.
  • Four electrically operated metering units deliver precise application rates between 0.5 and 500 kg/ha, as seeds flow continuously and evenly at all times due to a fine balance between chamber volume and speed of rotation.
  • The new blower fan has a stainless steel wheel and an aluminium housing which is integrated in the tank. This generates an adequate volume of air while keeping noise levels low.
  • The implement is optionally available with a weighing unit and filling auger to help refilling and shorten waiting times.
  • The parallelogram-guided double disc coulter system with depth control roller is available in a mechanical version (up to 45 kg coulter pressure) and a hydraulic version (up to 70 kg coulter pressure).

Select a model

Technical data

Solitair 25/400 KA Solitair 25/450 KA Solitair 25/500 KA Solitair 25/600 KA
Working width (cm) 400 450 500 600
Weight (kg) 1 967 2 098 2 215 2 478
Article number 750 5330 750 5331 750 5332 750 5333
Tank capacity (litres) 3 000 3 000 3 000 3 000
Number of rows with row spacing 12.5 cm (15cm) 32 (27) 36 (30) 40 (34) 48 (40)

Basic equipment

  • Electronic seed drill control MegaDrill with preparation for operation with any ISOBUS terminal
  • Hydraulically driven fan
  • Maintenance-free double disc coulters OptiDisc M, up to 45 kg coulter pressure per coulter
  • Forward folding hopper cover
  • Hopper with distributors located outside
  • Electronic hopper level indicator via 2 sensors at seed hopper (top)
  • 4 electrically driven metering units
  • Digital scale with case
  • Width sections electrically remote-controlled
  • Pulse wheel for MegaDrill, Ø 340 mm
  • Loading platform with steps
  • Without lighting equipment

The availability and basic equipment of the machine may vary depending on the country. Please contact your dealer.
