Juwel 8
- For tractors from 90 - 333 hp
- From 3 to 7 furrows
- Body spacing 90, 100 and 120 cm
The particularly versatile plough
The 3 - 7 furrow Juwel 8 impresses with a wide range of variants and available options. Like the Juwel 10, it is available with OF equipment for onland or in-furrow ploughing. The Juwel 8i has ISOBUS control and is therefore particularly easy to operate.
- Frame diameter 140 mm
- Frame height 80 cm
- Body spacing 90, 100 or 120 cm
- Also available with mechanical non-stop overload protection (X-versions) or hydraulic overload protection OptiStone (U-versions)
- Also available in OF version for onland and in-furrow ploughing
- Choice from an extensive range of plough bodies, skimmers and other equipment
![Anbaudrehpflug Juwel 8 von LEMKEN Seitenbild Anbaudrehpflug Juwel 8 von LEMKEN Seitenbild](/fileadmin/a_Webseite/00_Produkte/Bodenbearbeitung/Pfluegen/Anbaudrehpfluege/Juwel/Juwel_8/juwel-8-1.jpg)
Maximum operating comfort with ISOBUS: Juwel 8i
The iQ plough control brings ISOBUS ease of use to the Juwel 8i.
The following functions are controlled as standard on the Juwel 8 i via the CCI terminal or the tractor's ISOBUS system: plough rotation, front furrow width, pitch, working width, working depth adjustment via the hydraulic support wheel, independent setting of the onland offset for onland ploughs
Also available as an option: Operation of a furrow press, adjustment of the OptiStone overload protection, automatic plough turning
![Juwel 8i in action Juwel 8i in action](/fileadmin/_processed_/9/f/csm_juwel-8i-einsatz_3b56956177.jpg)
- The operable functions can be combined, stored and called up in up to four different scenarios. For a shallow last furrow, for example, a scenario is called up with a modified pitch and a flatter support wheel setting.
- The user guidance on the display is intuitive and clear.
- The integration of operating elements according to the ISOBUS standard IL4, such as joysticks or multifunction handles, can further increase operating comfort.
![Juwel 8i operation isobus Juwel 8i operation isobus](/fileadmin/_processed_/7/c/csm_juwel-8i-bedienung-isobus_78b4d23a60.jpg)
- A GPS-controlled working width adjustment is available with a CCI terminal. It enables ploughing with an exactly straight furrow or working to a target furrow, for example, to avoid another headland. It is possible to calculate the working width settings to achieve the target contour.
- An automatic towing arm control for ploughing with furrow press is available
- The large CCI-1200 terminal with 12.1" widescreen display provides the optimum overview of the working process by displaying and operating several functions.
![Juwel 8i operation CCI1200 working width Juwel 8i operation CCI1200 working width](/fileadmin/_processed_/6/9/csm_juwel-8i-_bedienung-CCI1200-arbeitsbreite_3e0ba1cf42.jpg)
Technical data
Juwel 8 M 4 N 90 | Juwel 8 M 4+1 N 90 | Juwel 8 M 5 N 90 | Juwel 8 M 5+1 N 90 | Juwel 8 M 6 N 90 | Juwel 8 M 6+1 N 90 | Juwel 8 M 3 N 100 | Juwel 8 M 3+1 N 100 | Juwel 8 M 4 N 100 | Juwel 8 M 4+1 N 100 | Juwel 8 M 5 N 100 | Juwel 8 M 5+1 N 100 | Juwel 8 M 6 N 100 | |
---|---|---|---|---|---|---|---|---|---|---|---|---|---|
Power requirements (hp) from - to | 110 - 160 | 130 - 200 | 130 - 200 | 140 - 240 | 140 - 240 | 160 - 300 | 90 - 120 | 110 - 160 | 110 - 160 | 130 - 200 | 130 - 200 | 140 - 240 | 140 - 240 |
Power requirements (kW) from - to | 81 - 118 | 96 - 147 | 96 - 147 | 103 - 176 | 103 - 176 | 118 - 221 | 66 - 88 | 81 - 118 | 81 - 118 | 96 - 147 | 96 - 147 | 103 - 176 | 103 - 176 |
Weight (kg) | 1 314 | 1 545 | 1 530 | 1 761 | 1 746 | 1 977 | 1 113 | 1 348 | 1 333 | 1 568 | 1 553 | 1 788 | 1 774 |
Article number | 80 4351L | 80 4352L | 80 4353L | 80 4354L | 80 4355L | 80 4356L | 80 4357L | 80 4358L | 80 4359L | 80 4360L | 80 4361L | 80 4362L | 80 4363L |
Working width per furrow (cm) | 30, 35, 40, 45 | 30, 35, 40, 45 | 30, 35, 40, 45 | 30, 35, 40, 45 | 30, 35, 40, 45 | 30, 35, 40, 45 | 33, 38, 44, 50 | 33, 38, 44, 50 | 33, 38, 44, 50 | 33, 38, 44, 50 | 33, 38, 44, 50 | 33, 38, 44, 50 | 33, 38, 44, 50 |
Number of furrows | 4 | 4+1 | 5 | 5+1 | 6 | 6+1 | 3 | 3+1 | 4 | 4+1 | 5 | 5+1 | 6 |
Body spacing (cm) | 90 | 90 | 90 | 90 | 90 | 90 | 100 | 100 | 100 | 100 | 100 | 100 | 100 |
Basic equipment
- Hydraulic turnover device M 120
- Double acting turnover device
- Box section frame 140 x 140 x 10 mm
- Setting Centre Optiquick©
- Lower link attachment Cat. 3 (or Cat. 3N=L2 Z3, Cat. 4N= L3 Z4 or Cat. 4)
- Tools and shearbolts
- Stand
- Underframe clearance 80 cm
- Two-piece shares (option: hard-faced one-piece stone shares)
- Hard-faced points
- Shape of DuraMaxx bodies W 40 or W 52
The availability and basic equipment of the machine may vary depending on the country. Please contact your dealer.
